Details
F 2260 Ø60 mm, Graphite Brushes, 80 Watt
Part number 2260.880-51.216-200
Price scales
Quantity
Price per unit
Prices excluding VAT and shipping costs
1-4
€684.30
5-19
€528.30
20-49
€423.67
from 50
On request
Specifications
Values at nominal voltage
Nominal voltage
15 V
No load speed
3950 rpm
No load current
583 mA
Nominal speed
13300 rpm
Nominal torque (max. continuous torque)
-32 mNm
Nominal current (max. continuous current)
0.00238 A
Stall torque
9960 mNm
Stall current
290 A
Max. efficiency
86 %
Characteristics
Terminal resistance
0.179 Ω
Terminal inductance
0.000066 mH
Torque constant
34.4 mNm/A
Speed constant
278 rpm/V
Speed / torque gradient
1.34 rpm/mNm
Mechanical time constant
21.3 ms
Rotor inertia
1380 gcm²
Thermal data
Thermal resistance housing-ambient
3.4 K/W
Thermal resistance winding-housing
1.1 K/W
Thermal time constant winding
75.3 s
Thermal time constant motor
2210 s
Ambient temperature
-20...+100 °C
Max. winding temperature
+125 °C
Mechanical data
Bearing type
ball bearings
Max. speed
4000 rpm
Axial play
0.05 - 0.15 mm
Max. axial load (dynamic)
15 N
Max. force for press fits (static)
400 N
(static, shaft supported)
10000 N
Max. radial load
100 N, 5 mm from flange
Other specifications
Number of pole pairs
2
Number of commutator segments
26
Number of autoclave cycles
0
Product
Weight
1300 g
Continuous operation range Short term operation range
Description
maxon DC motors are high-quality motors fitted with powerful permanent magnets. The “heart”of the motor is the worldwide patented ironless rotor. For you, this means cutting-edge technology in compact, powerful and low inertia drives.
